Corn Washing Machine
The corn washing machine can process whole corn or corn kernels. It is convenient for the quick freezing corn in the later stage.Corn washing machine is to rinse the material
Key Parameters
| Capacity | 500-3000kg/h |
|---|---|
| Material | SUS304 stainless steel |
| Voltage | Customized according to local power supply |
| Dimensions | Approx. 3500-8000 x 1000-1600 x 1650 mm |
Suitable Materials
How the Line Works
Continuous processing stages take raw material from feeding to clean, dry and pack-ready product.
Feeding
Washing
Spray rinsing
Discharging
Standard Configuration
Each unit can be added, removed or resized according to your material and capacity.
Main Processing Chamber
Core washing or processing area built with food-grade stainless steel.
Water Circulation / Spray System
Improves cleaning performance while reducing water waste.
Brush / Roller / Conveyor Unit
Configured according to product shape and cleaning requirements.
Discharge Conveyor
Transfers finished material smoothly to the next step.
Control Cabinet
Simple controls for daily operation and adjustment.
Technical Specifications
Final parameters are confirmed in the technical agreement after layout design.
| Capacity | 500-3000kg/h |
|---|---|
| Material | SUS304 stainless steel |
| Voltage | Customized according to local power supply |
| Dimensions | Approx. 3500-8000 x 1000-1600 x 1650 mm |
| Model | JS-CW-2000 |
| Main Power | 4.0-12 kW |
| Water Consumption | 0.8-2.2 m3/h |
| Approx. Weight | 800-2600 kg |
| Applicable Materials | corn; sweet corn; corn kernels |
| Layout | Standalone machine or customized line layout |
| Customization | Capacity, dimensions, inlet/outlet height and optional modules can be customized |
Frequently Asked Questions
Can't find your answer? Contact our engineers
Sweet corn, corn cobs and similar firm produce can be washed with spray or bubble sections before cutting or packing.
Yes. Joyshine configures 500-3000kg/h, conveyor width, inlet and outlet height, tank length and optional modules according to your workshop.
Spray rinsing, elevator discharge, inspection and dewatering modules can be added for corn processing.
Yes. The equipment can be assembled and test-run with water or sample material before packing, with photos or videos for confirmation.
The corn washing machine can process whole corn or corn kernels. It is convenient for the quick freezing corn in the later stage.Corn washing machine is to rinse the material
This product can be configured according to raw material type, target capacity, workshop space and downstream processing requirements. Joyshine can provide layout suggestions, equipment matching and test-running support before delivery.
